DELIXI ELECTRIC · ZCD-1224/15A
Product overview
DELIXI ZCD-1224/15A automatically switches between 12V and 24V battery charging and provides the documented10A/15A current selection.
Technical selection summary
| Input | AC220V±15%; 50Hz±5Hz |
|---|---|
| Battery voltage | 12V/24V automatic switching within this unit |
| Charging current | 10A or 15A potentiometer selection on the 15A unit; not a 30A construction |
| Charging sequence | Constant-current, equalizing and trickle/float stages; voltage limit14V/27.5V±0.5V |
| Protection | Reverse-polarity and short-circuit protection; output cut-off at 85°C±15°C |
| Dielectric test | Input–output and input–case:1.5kVAC |
| Dimensions | 208W×175D×88Hmm; package275×200×175mm |
The voltage selection is automatic and 10A/15A is an adjustment of this15A model. The older30A photo is replaced by the current manufacturer catalogue illustration. State battery chemistry and capacity for matching; no unlisted lithium/BMS compatibility is promised.
Typical applications
- DELIXI ZCD-1224/15A automatically switches between 12V and 24V battery charging and provides the documented10A/15A current selection..
Specify your enquiry
For a focused quotation, include:
- Charging Current: 10A, 15A
- Required quantity, load, exact installation and supplied version.
ZCD exact manufacturer catalogue (Chinese PDF)
Product reference images and drawings
