DELIXI · DIN-rail redundancy module
Product overview
The DELIXI CDRM-60V-20A is a DIN-rail redundancy module for N+1 or 1+1 DC power-supply arrangements. The manufacturer’s 2026-01-26 reference specifies a 22–60 V DC input range and a rated 20 A output, with input-status indication and dry-contact monitoring.
Technical selection summary
| Brand and model | DELIXI CDRM-60V-20A |
|---|---|
| Product type | Metal-case DIN-rail redundancy module |
| Input-voltage range | 22–60 V DC |
| Rated output / current range | 20 A rated output; 0–20 A current range |
| Output-voltage reference | Output follows the input; manufacturer reference: INPUT −0.5 V |
| Redundancy arrangements | N+1 or 1+1 according to the system design |
| Input-status monitoring | Corresponding LED indication extinguishes and the dry contact opens when an input is lost, according to the reference |
| Cooling | Natural cooling |
| Operating conditions | −35°C to +70°C ambient reference; altitude up to 2000 m; confirm derating and ventilation |
| Mounting / dimensions | TS35/7.5 or TS35/15 rail; drawing dimensions A/B/C: 113.5/125.2/40 mm |
The 60 V designation is not a fixed regulated 60 V output. Select compatible DC supplies and the redundancy arrangement for the actual load, keeping the module’s rated output-current reference in view. Confirm wiring, monitoring-contact requirements and installation conditions from the exact CDRM model.
Typical applications
- DC control systems requiring a matched redundant supply arrangement
- Industrial cabinets using N+1 or 1+1 power-supply redundancy
Specify your enquiry
For a focused quotation, include:
- Exact CDRM-60V-20A quantity and required redundancy arrangement
- Input-supply voltages, individual supply ratings and total load current
- Required output voltage and permitted voltage drop
- DC OK/dry-contact monitoring requirements
- Rail, wiring, ventilation and installation space
