NewTrend 29450 Spring-terminal Standard Auxiliary Contact, 1CO

NewTrend29450 standard auxiliary changeover contact for breaker position or trip signalling. Spring-terminal version.

Model
Contacts
Contact Type
AC-12 at AC240V
Add to Enquiry
SKU: 1770405948997771264 Category: MCCB Circuit Breaker
  • Description
  • Additional information
  • Technical Documents
  • Selection & Ordering
Description

NewTrend · 29450

Product overview

NewTrend29450 standard auxiliary changeover contact for breaker position or trip signalling. Spring-terminal version.

Technical selection summary

ParameterSpecification
Contact function1 common changeover contact,1NO+1NC; OF/SD/SDE/SDV function depends on installed position
Contact versionStandard29450; low-level29452 is a separate product
AC operational currentAC12:6A across the listed24-690V rows. AC15:6A24/48V;5A110V;4A220/240V;2A380/440V;1.5A480V;0.1A660/690V
DC operational currentDC12:6A24V;2.5A48V;0.6A110V;0.3A250V. DC14:1A24V in the current standard-contact reference;0.2A48V;0.05A110V;0.03A250V
TerminalsMinimum reference load100mA at24VDC. Spring-terminal structure; inspect the4-2-C1 marking; wiring range0.5-1.5mm2 reference
Ratings distinctionAC12 operational current is6A; current spring-terminal reference Ith is5A. The old6A thermal row applies to an earlier construction
CompatibilityConfirm exact MCCB model, accessory slot and SDE adaptor; similar case shape does not establish interchangeability

The function is set by the mounting position; one part is not four independent signalling contacts. Select the exact breaker and terminal structure in the enquiry. This NewTrend accessory does not inherit Schneider certifications. Low-level5A contacts are not selectable on this page.

Typical applications

  • Low-voltage distribution and control applications

Open technical reference image

Product reference images and drawings

29450 technical reference 129450 technical reference 229450 technical reference 3
Additional information
Model

29450

Contacts

1CO

Contact Type

Standard

AC-12 at AC240V

6A

Technical Documents

TECHNICAL RESOURCES

Documents for NewTrend 29450 Spring-terminal Standard Auxiliary Contact, 1CO

A downloadable document is not currently attached to this listing. Request the datasheet for your required model and configuration.

Request a datasheet

Drawings and compliance documents

Tell us the model and destination market if you need dimensions, a wiring diagram or a certification document. Available documents and approvals depend on the exact product configuration.

Ask for product documents

Supplier: Shanghai Newtrend Electric Co., Ltd. Brand and manufacturer details are stated separately for each product.

Selection & Ordering

BEFORE YOU ORDER

Selection and ordering questions

What information is needed for a quotation?

Send the exact model or selected configuration, required quantity, destination country and any project-specific requirements. Our team will confirm availability and the matching specification.

Are the same approvals available for every configuration?

No. Standards, certificates and market acceptance must be checked for the exact manufacturer model and configuration. Request the relevant document before specifying the product.

Can I include other products in the same enquiry?

Yes. Add the required products to your quote list, set the quantities and send one enquiry with your project requirements.
