NewTrend NF-CW Moulded Case Circuit Breaker Family
Click to enlarge
Home Circuit Breaker & Fuses MCCB Circuit Breaker NewTrend NF-CW Moulded Case Circuit Breaker Family
CHINT NQ2 Enclosed Direct Online Motor Starter
CHINT NQ2 Enclosed Direct Online Motor Starter
Back to products
CH Type 4 Space Load Center
CH Type 4 Space Load Center

NewTrend NF-CW Moulded Case Circuit Breaker Family


You save

The NewTrend / OEM NF-CW listing covers multiple moulded-case circuit-breaker frames. Choose the actual frame, trip current and poles before confirming the rated operational voltage and interruption performance.

Poles
Rated Current
Add to Enquiry
SKU: 60046080598 Category: MCCB Circuit Breaker
  • Description
  • Catalog
Description

NewTrend / OEM · Moulded case circuit breaker

Product overview

The NewTrend / OEM NF-CW listing covers multiple moulded-case circuit-breaker frames. Choose the actual frame, trip current and poles before confirming the rated operational voltage and interruption performance.

Technical selection summary

SeriesNF-CW
Frame range in supplied tableNF30-CW through NF800-CW
Current referenceUp to 800 A across different frames
Poles2P, 3P or 4P depending on frame
CircuitAC 50/60 Hz
Fault-duty selectionConfirm Icu and Ics at the actual operating voltage

Breaking capacity varies by frame and voltage. An insulation-voltage value is not the rated operational voltage. This NewTrend / OEM offer does not establish another manufacturer’s approvals or interchangeability.

Typical applications

  • Industrial AC distribution
  • Panel-builder procurement
  • Replacement by full frame and trip code

Model-specific reference data

Compare the exact model, voltage and duty. Reference tables may include other frames or versions; confirm the ordered configuration before using any rating or dimension.

Model comparison

Application
NF-CW series Moulded Case Circuit Breaker is a kind of economic breaker, has the features as following, such as steady and reliable property, reasonable structure, beautiful style, small volume, etc. This breaker applies to the circuit with AC50/60Hz, rated insulation voltage 660V, max rated current 800A as on-off operation, and take effect, it also can be used as unfrequent conversion of line and unfrequency.
Specifications
Type

Pole

number
Rated current

(A)
Circuit breaking capacity (KA)
AC(P1/P2)
240
380
415
500
600660
NF30-CW
2
3,5,10,15,20,30
5/5
5/2.5
2.5/1.5
2.5/1.0
––
3
NF50-CW
3
10,20,30,40,50
5/10
10/7.5
7.5/5
7.5/5
2.5/1.5
–
NF60-CW
3
10,20,30,40,50,60
5/10
10/7.5
7.5/5
7.5/5
2.5/1.5
–
NF100-CW
3
60,75,100
50/42
30/20
7.5/5
15/10
10/5
5/2.5
4
NF250-CW
3
125,150,175,200,225,250
50/42
30/22
25/15
18/15
15/10
5/2.5
4
NF400-CW
3
250,300,350,400
85/60
50/35
25/20
35/25
25/18
15/10
4
NF630-CW
3
500,600,630
85/60
50/35
50/30
35/25
25/18
15/10
4
NF800-CW
3
600,700,800
85/60
50/35
50/30
35/25
25/18
15/10
