NewTrend NS630bN-NS1600N Electrically Operated MCCB, 3P/4P


You save

NewTrend N-class electrically operated NS-style circuit breakers. Select current,poles,Micrologic protection and the separate motor-module supply.

Model
Poles
Rated Current
Micrologic
Motor Module Supply
Construction
Icu at AC380/415V
Ics at AC380/415V
Add to Enquiry
SKU: 1600231104486 Category: MCCB Circuit Breaker
  • Description
  • Catalog
Description

NewTrend · NS

Product overview

NewTrend N-class electrically operated NS-style circuit breakers. Select current,poles,Micrologic protection and the separate motor-module supply.

Technical selection summary

ParameterSpecification
VersionFixed electrically operated N-class,630/800/1000/1250/1600A;not manual NS or NS1600b-3200
Main circuitAC50/60Hz,Ue≤690V;Ui800V;Uimp8kV
Electrical-operation IcuAC220/240V50kA;380/415V50kA;440V50kA;500/525V40kA;660/690V30kA
Electrical-operation IcsAC220/240V37kA;380/415V37kA;440V37kA;500/525V30kA;660/690V22kA
Protection2.0/2.0A basic;5.0/5.0A selective;6.0A adds earth-fault;7.0A adds earth-leakage. A denotes ammeter; no automatic E/P upgrade
Motor moduleIntegrated spring-charging motor,opening and closing releases;choose exact supply independently of main voltage
Module suppliesStandard fixed-module order table:AC48/100-130/220-240/277/380-415V50/60Hz;DC24-30/48-60/100-130/200-250V
Mechanism duty0.85-1.1Un;180VA/W reference;charging≤4s;maximum3cycles/minute;closing response60ms±10 atUn
AssemblyBasic breaker,control unit,top/bottom connections andmotor mechanism form complete device;communication version is separate enquiry
Neutral / wiring3P+N and residual protection require corresponding external sensors/voltage sensing and exact reference diagram
Supply identityNewTrend/OEM using owner-authorised Schneider reference parameters;no Schneider certification or original order number is inherited

The2022 exact electrical-operation catalogue is used under owner authorisation. Ics37kA at380/415V must not be replaced by the50kA manual-version value. Other breaking classes,drawout arrangements and communicating modules require their own complete specification.
