HKA1-41 30mm 4 Position Joystick Switch
Click to enlarge
Home Automation & Control Pushbuttons HKA1-41 30mm 4 Position Joystick Switch
HKA1-41Z02 30mm 2-Way Joystick Switch
HKA1-41Z02 30mm 2-Way Joystick Switch
Back to products
XD2PA 22mm 4 Direction Joystick Controller Switch
XD2PA 22mm 4 Direction Joystick Controller Switch

HKA1-41 30mm 4 Position Joystick Switch


You save

The supplied HKA1-41QY reference concerns a 30 mm multi-direction joystick with maintained action. Select the exact contact schematic and operator construction.

Rated Voltage
Size
Add to Enquiry
SKU: 60577065612 Category: Pushbuttons
  • Description
  • Catalog
Description

NewTrend / OEM · Joystick control switch

Product overview

The supplied HKA1-41QY reference concerns a 30 mm multi-direction joystick with maintained action. Select the exact contact schematic and operator construction.

Technical selection summary

Listing / reference modelHKA1-41QY
Product typeJoystick control switch

Distinguish Z/Y action, contact count and button-equipped variants. AC and DC contact ratings have different conditions; do not transfer a maximum current across voltages or load categories. Specify direction count, momentary or maintained action, NO/NC contacts and whether a top button is required. Match the complete suffix and contact diagram; a similar joystick outline does not establish the switching sequence or load duty.

Product reference images and drawings

Use the matching model and version in the reference data. Confirm the applicable rating, test conditions and dimensions against the exact supplied unit.

Product NameJoystick Switch
ModelHKA1-41Z02HKA1-41Y02HKA1-41Z04HKA1-41Y04HKA1-42Z04HKA1-42Y04HKA1-41QZHKA1-41QY
Reference Photo: HKA1-41QY supplied technical referenceHKA1-41QY supplied technical referenceHKA1-41QY supplied technical reference
Action TypeMomentaryLatchingMomentaryLatchingMomentaryLatchingMomentaryLatching
Position2 Position4 Position
Contact Type2NO4NO8NO4NO 4NC
Contact FigureHKA1-41QY supplied technical referenceHKA1-41QY supplied technical reference  HKA1-41QY supplied technical referenceHKA1-41QY supplied technical reference
Voltage & CurrentAC 380V, max 15A0.6A 125Vdc, 0.3A 250Vdc, 15A 125Vac/250Vac
Fixing Hole30mm diameter
Angle±30°
Mechanical Life100 Thousand times
Electrical Life100 Thousand times

HKA1-41QY supplied technical reference

HKA1-41QY supplied technical reference

HKA1-41QY supplied technical reference
