NewTrend / OEM · Joystick control switch
Product overview
The supplied HKA1-41Z02 reference concerns a 30 mm two-direction joystick with momentary action. Select the exact contact schematic and operator construction.
Technical selection summary
| Listing / reference model | HKA1-41Z02 |
|---|---|
| Product type | Joystick control switch |
Distinguish Z/Y action, contact count and button-equipped variants. AC and DC contact ratings have different conditions; do not transfer a maximum current across voltages or load categories. Specify direction count, momentary or maintained action, NO/NC contacts and whether a top button is required. Match the complete suffix and contact diagram; a similar joystick outline does not establish the switching sequence or load duty.
Specify your enquiry
For a focused quotation, include:
- Complete model, configuration and quantity
- Operating voltage, current and application duty
- Coil / protection selection, mounting and wiring requirements
- Nameplate photograph and required technical documents
Product reference images and drawings
Use the matching model and version in the reference data. Confirm the applicable rating, test conditions and dimensions against the exact supplied unit.
| Product Name | Joystick Switch | |||||||
| Model | HKA1-41Z02 | HKA1-41Y02 | HKA1-41Z04 | HKA1-41Y04 | HKA1-42Z04 | HKA1-42Y04 | HKA1-41QZ | HKA1-41QY |
| Reference Photo: |  |
 |
 |
|||||
| Action Type | Momentary | Latching | Momentary | Latching | Momentary | Latching | Momentary | Latching |
| Position | 2 Position | 4 Position | ||||||
| Contact Type | 2NO | 4NO | 8NO | 4NO 4NC | ||||
| Contact Figure |  |
 |
 |
 |
||||
| Voltage & Current | AC 380V, max 15A | 0.6A 125Vdc, 0.3A 250Vdc, 15A 125Vac/250Vac | ||||||
| Fixing Hole | 30mm diameter | |||||||
| Angle | ±30° | |||||||
| Mechanical Life | 100 Thousand times | |||||||
| Electrical Life | 100 Thousand times | |||||||
