DELIXI ELECTRIC · Residual-current circuit breaker with overcurrent protection
Product overview
The DELIXI CDB6LESi combines residual-current, overload and short-circuit protection for low-voltage AC distribution. Specify the complete pole, current, curve, residual-current and construction code; the standard and S delay versions have different selection limits.
Technical selection summary
| Manufacturer series | CDB6LESi; do not substitute the G or H construction without its exact rating and documents |
|---|---|
| Poles / voltage | 1P+N or 2P: AC 230 V; 3P, 3P+N or 4P: AC 400 V; 50/60 Hz |
| Current / delay scope | Standard: 6–63 A; S delay: 32–63 A |
| Residual-current selection | Shown 30/100/300 mA values apply to documented standard constructions. S delay offers 50/75/100/300 mA; no S 30 mA selection |
| Trip curve / type | B, C or D thermal-magnetic curve; residual-current Type AC or Type A must be specified separately |
| Short-circuit reference | 6 or 10 kA construction; confirm the exact marked rating, not a universal series value |
| Isolation / wiring | 1P+N and 3P+N are not suitable for isolation. Top feed applies to all listed poles; bottom feed only to documented 1P+N/2P constructions |
| Mounting / enclosure | 35 mm DIN rail; IP20 directly installed, IP40 in a suitable distribution box; terminal reference up to 25 mm², 2.5 N·m |
| Standard / environment | IEC 61009-1 / GB/T 16917.1; −35 to +70 °C, daily average ≤35 °C; check installation and derating conditions |
The residual-current and curve selections do not define pole count, current rating, Type A/AC response or the delay construction. Include the full code before ordering. Overvoltage protection is an option on specified constructions, not a standard function of every unit. RoHS construction and accessories require separate confirmation.
Typical applications
- Distribution circuits requiring residual-current and overcurrent protection
- Replacement procurement with a matched pole arrangement and complete protection code
