DELIXI DZ47L1E Electronic RCCB, 10–63A 30mA

Manufacturer catalogue illustration.

DELIXI DZ47L1E is an electronic residual-current protection switch. Select current and 2P/4P construction for the documented30mA AC-type version.

Model
Poles
Rated Current
Residual Current
Leakage Type
Add to Enquiry
SKU: DZ47L1E Category: Delixi RCCB RCBO
  • Description
  • Catalog
Description

DELIXI ELECTRIC · DZ47L1E

Product overview

DELIXI DZ47L1E is an electronic residual-current protection switch. Select current and 2P/4P construction for the documented30mA AC-type version.

Technical selection summary

Current options10A, 16A, 20A, 25A, 32A, 40A, 63A
Poles / supply2P:AC230V; 4P:AC400V; 50Hz
Residual current / type30mA; AC type
Protection functionResidual-current protection; no thermal-magnetic overcurrent function is established for this RCCB
Conditional short-circuit rating6kA with coordinated external protection; not a standalone overcurrent breaking rating
Mounting / terminalsTH35-7.5 rail; top supply; 25mm²; 2N·m

The exact leaflet lists residual protection and conditional short-circuit current. The former unsupported overload/short-circuit trip description is removed. Provide an appropriately coordinated overcurrent protective device.

Typical applications

  • Electrical distribution or control circuits within the selected manufacturer ratings.

Product reference images and drawings

DZ47L1E exact manufacturer selection and ratings page 1
Catalog
NameSizeRelease timeOperate
Delixi DZ47L1E Electronic RCCB.pdf770.37 KB2026-10-28Download
