CHINT NH40SZ 100A 4P Automatic Changeover Switch
CHINT NH40SZ 100A 4P Automatic Changeover Switch
Click to enlarge
CHINT NH40SZ 100A 4P Automatic Changeover Switch
CHINT NH40SZ 100A 4P Automatic Changeover Switch
Home Electrical Accessories Others CHINT NH40SZ 100A 4P Automatic Changeover Switch
CHINT NH40SZ 800A 4P Automatic Changeover Switch
CHINT NH40SZ 800A 4P Automatic Changeover Switch
Back to products
Chint NC1 4P 2NO+2NC Contactor
Chint NC1 4P 2NO+2NC Contactor

CHINT NH40SZ 100A 4P Automatic Changeover Switch

Series illustration: photo shows a16A/4P unit. This page is 100A/4P.

CHINT NH40SZ transfers the 100A,4-pole load between two supplies. Select the common,SZI,SZII or SZIII controller to match mains/mains or mains/generator operation.

Model
Poles
Rated Current
Controller Type
Control Supply
Add to Enquiry
SKU: 1770404227667992576 Category: Others
  • Description
  • Catalog
Description

CHINT · NH40SZ 100A 4P Automatic Changeover Switch

Product overview

CHINT NH40SZ transfers the 100A,4-pole load between two supplies. Select the common,SZI,SZII or SZIII controller to match mains/mains or mains/generator operation.

Technical selection summary

This page current / poles100A;4P; switched neutral on4P
Main circuit / control supplyAC400V main circuit in the retained technical table;AC220V control;50Hz
Common SZAutomatic changeover and automatic return; normal supply has priority
SZIMains/mains mutual standby; no automatic return while the standby source remains healthy
SZIIMains/mains automatic changeover and automatic return; phase-loss,overvoltage and undervoltage detection
SZIIIMains/generator automatic changeover and return; generator start signal and warm-up/cool-down control
Transfer functionAutomatic,remote and manual modes on I/II/III; mechanical and electrical interlocking
Switch functionChangeover switch-disconnector; use correctly coordinated upstream overcurrent protection
Series illustrationThe shared product photo shows a16A/4P unit only. This page selection is 100A/4P; the photo nameplate does not define the ordered current,poles or controller.

Series illustration: the common photograph is16A/4P and does not represent the exact ordered assembly. Choose the controller function independently of the fixed current/poles on this page. L/X/F/Y/enclosure and other derived suffixes require their own confirmed complete reference.

Typical applications

  • CHINT NH40SZ transfers the 100A,4-pole load between two supplies.

Open retained manufacturer catalogue image

Product reference images and drawings

NH40SZ 100A / 4P retained manufacturer reference page 1NH40SZ 100A / 4P retained manufacturer reference page 2NH40SZ 100A / 4P retained manufacturer reference page 3NH40SZ 100A / 4P retained manufacturer reference page 4NH40SZ 100A / 4P retained manufacturer reference page 5NH40SZ 100A / 4P retained manufacturer reference page 6NH40SZ 100A / 4P retained manufacturer reference page 7NH40SZ 100A / 4P retained manufacturer reference page 8NH40SZ 100A / 4P retained manufacturer reference page 9NH40SZ 100A / 4P retained manufacturer reference page 10
Catalog
NameSizeRelease timeOperate
