NewTrend THQL2150 2P Plug-In Circuit Breaker, 50A, 10kA
NewTrend THQL2150 2P Plug-In Circuit Breaker, 50A, 10kA
NewTrend THQL2150 2P Plug-In Circuit Breaker, 50A, 10kA
NewTrend THQL2150 2P Plug-In Circuit Breaker, 50A, 10kA
Click to enlarge
NewTrend THQL2150 2P Plug-In Circuit Breaker, 50A, 10kA
NewTrend THQL2150 2P Plug-In Circuit Breaker, 50A, 10kA
NewTrend THQL2150 2P Plug-In Circuit Breaker, 50A, 10kA
NewTrend THQL2150 2P Plug-In Circuit Breaker, 50A, 10kA
Home Electrical Accessories Others NewTrend THQL2150 2P Plug-In Circuit Breaker, 50A, 10kA
NewTrend QL130 Plug-In Circuit Breaker, 1P, 30A
NewTrend QL130 Plug-In Circuit Breaker, 1P, 30A
Back to products
NewTrend A-800 Single-hole Aluminum Mechanical Lug
NewTrend A-800 Single-hole Aluminum Mechanical Lug

NewTrend THQL2150 2P Plug-In Circuit Breaker, 50A, 10kA


You save

NewTrend THQL2150 2P plug-in thermal-magnetic circuit breaker, 50A, AC 120/240V, 10kA. 50.8 mm nominal width, for matching NewTrend PowerMark TL / TLM load centers.

Poles
Rated Current
Add to Enquiry
SKU: 1600800958666 Category: Others
  • Description
  • Catalog
Description

NewTrend · THQL Series · Full-Size Plug-In Circuit Breaker

Product overview

The NewTrend THQL2150 is a full-size two-pole plug-in thermal-magnetic circuit breaker for residential and light-commercial distribution. It combines overload protection, short-circuit protection and manual ON/OFF switching.

Rated current: 50A at AC 120/240V. The 50.8 mm-wide breaker occupies two full-size panel spaces. It installs onto the busbar in matching NewTrend PowerMark TL / TLM load centers.

Key features

  • Full-size two-pole design: 50.8 mm nominal width with a plug-in busbar connection.
  • Thermal-magnetic protection: Thermal response to sustained overloads and magnetic response to short circuits.
  • 10 kA interrupting capacity: Rated at AC 120/240V.
  • Manual switching and reset: Front operating handle with ON, OFF and tripped positions.
  • Matching distribution range: For NewTrend PowerMark TL / TLM load centers.

Technical selection summary

BrandNewTrend
SeriesTHQL
Product typePlug-in thermal-magnetic circuit breaker
Number of poles2P
Rated current50A
Rated voltageAC 120/240V
Frequency50/60 Hz
Interrupting capacity10 kA at AC 120/240V
Panel spaceTwo full-size panel spaces · 50.8 mm nominal width
ProtectionThermal overload and magnetic short-circuit protection
OperationManual ON/OFF switching and automatic tripping
MountingPlug-in busbar connection
Matching load centersNewTrend PowerMark TL / TLM series

THQL Series Selection Table

ProductModelPolesRated CurrentRated Voltage
NewTrend THQL 1P plug-in circuit breakerTHQL 1PTHQL11151P15AAC 120/240V
THQL11201P20AAC 120/240V
THQL11251P25AAC 120/240V
THQL11301P30AAC 120/240V
THQL11351P35AAC 120/240V
THQL11401P40AAC 120/240V
THQL11451P45AAC 120/240V
THQL11501P50AAC 120/240V
NewTrend THQL 2P plug-in circuit breakerTHQL 2PTHQL21152P15AAC 120/240V
THQL21202P20AAC 120/240V
THQL21252P25AAC 120/240V
THQL21302P30AAC 120/240V
THQL21352P35AAC 120/240V
THQL21402P40AAC 120/240V
THQL21452P45AAC 120/240V
THQL21502P50AAC 120/240V
THQL21602P60AAC 120/240V
THQL21702P70AAC 120/240V
THQL21802P80AAC 120/240V
THQL21902P90AAC 120/240V
THQL211002P100AAC 120/240V
THQL211102P110AAC 120/240V
THQL211252P125AAC 120/240V
NewTrend THQL 3P plug-in circuit breakerTHQL 3PTHQL320153P15AAC 240V
THQL320203P20AAC 240V
THQL320253P25AAC 240V
THQL320303P30AAC 240V
THQL320353P35AAC 240V
THQL320403P40AAC 240V
THQL320453P45AAC 240V
THQL320503P50AAC 240V
THQL320603P60AAC 240V
THQL320703P70AAC 240V
THQL320803P80AAC 240V
THQL320903P90AAC 240V
THQL321003P100AAC 240V

This page offers THQL2150 · 2P · 50A.

Dimensions — THQL 2P

Rated CurrentWidthHeightBody Depth
50A50.8 mm83.3 mm60.0 mm

Approximate housing dimensions. Maximum depth including the operating handle is approximately 74.2 mm. Two full-size panel spaces are required.

Installation and operation

Select the rated current to suit the circuit load and conductor rating. Use the matching NewTrend PowerMark TL or TLM load center and follow the terminal markings and tightening instructions. After a trip, locate and clear the fault, move the handle fully to OFF, then switch to ON. Installation and servicing should be carried out by qualified personnel with the supply isolated.

Typical applications

  • Residential lighting and socket branch circuits.
  • Branch-circuit protection in NewTrend PowerMark TL / TLM load centers.
  • Light-commercial AC distribution panels.

Matching PowerMark Load Centers

NewTrend PowerMark TL TLM load centerNewTrend multi-space PowerMark load centerNewTrend PowerMark Load CentersExplore the full range of TL / TLM circuit sizes, enclosures and interior assemblies.View all PowerMark load centers →
