NewTrend · SP1-63V
Product overview
NewTrend SP1-63V single-phase automatic recovery protector with separate voltage and current displays. Select the40A or63A version and set protection limits for the installation.
Technical selection summary
| Parameter | Specification |
|---|---|
| Function | Overvoltage, undervoltage and overcurrent protection with automatic recovery; voltage and current display |
| Supply | AC220V +/-10%,50/60Hz; not an AC380V three-phase unit |
| Adjustable current reference | 1-63A source range; selected nominal product current and actual wiring limits govern the setting |
| Overvoltage setting | AC230-300V |
| Undervoltage setting | AC140-210V |
| Delay reference | 1-300s in source; confirm trip/recovery setting logic against the supplied operating instructions |
| Power / endurance | <2W;100000 mechanical operations per supplier table |
| Mounting / outline | 35mm DIN rail; original outline line reads35L x140W x77H mm and is retained as printed, not an independently verified installation drawing |
This is not a substitute for a correctly coordinated short-circuit protective device. The original dimension labelling is ambiguous; confirm the physical outline before cabinet machining. AC380V and independent protection-only variants are not supported by this page.
Typical applications
- Electrical distribution and protection
Specify your enquiry
For a focused quotation, include:
- Selected model and configuration
- Quantity, installation requirements and destination
- Required supporting documents for the exact configuration
Open technical reference image
Product reference images and drawings
