ABB ACS510 reference · Frequency inverter
Product overview
This ABB ACS510-01-04A1-4 drive reference retains the original ACS510 family overview, application information and technical illustrations.
Technical selection summary
| Listing / reference model | ACS510-01-04A1-4 |
|---|---|
| Product type | Frequency inverter |
| Catalogue mains supply | Three-phase 380–480 V; 48–63 Hz (ABB Rev D) |
| Normal-use output current I2N | 4.1 A; use the exact model and derating conditions |
| Catalogue weight reference | R1 IP21 / UL Type 1: 6.5 kg; IP54 / UL Type 12: 8.2 kg |
| ABB frame / dimensional reference | ABB catalogue 3ABD00017601 Rev D (2009), pages 5–6: this exact ACS510 type is frame R1; match the enclosure and option code |
| IP21 / UL Type 1 dimensions | H1 369 mm; H2 330 mm; W 125 mm; D 212 mm. H1 includes the cable connection box; H2 excludes it |
| IP54 / UL Type 12 dimensions | H 449 mm; W 213 mm; D 234 mm. This is a separate enclosure option; confirm the full supplied type code |
The linked ABB ACS510 catalogue is the historical Rev D manufacturer reference. Match the complete ACS510-01 code, motor duty, frame and IP21/IP54 construction. Dimensions and weight depend on frame and enclosure options; confirm the supplied unit and its documentation.
Typical applications
- Variable-speed control of compatible AC motors.
- Pump, fan and conveyor applications matched to motor and drive ratings.
Specify your enquiry
For a focused quotation, include:
- Complete model, configuration and quantity
- Operating voltage, current and application duty
- Coil / protection selection, mounting and wiring requirements
- Nameplate photograph and required technical documents
ABB ACS510 technical catalogue — Rev D, pages 5, 6 and 13 (PDF)
