3-Phase MCB/MCCB Main Breaker Distribution Board 4-16 Ways

Name: 3-Phase MCB/MCCB Main Breaker Distribution Board 4-16 Ways
Brand: NewTrend
SKU: 1601212942093

rated voltage:380V,400V,415V
Brand Name:NewTrend
Place of Origin:China
Model Number:TD01
Rated Current:200A,250A
Product Name:Distribution Box
Application:Electric Power Transmission
Type:Distribution Box Electrical Boxes
Standard:BS/EN 61439-1
Warranty:2 Years

Material

Size

SKU: 1601212942093 Category: Others

Description

Product Description

TD01 Three phase distribution board

Main incomer: MCB or MCCB

Main incoming current: 125A, 160A, 200A, 250A

The distribution board divides the electrical power feed into subsidiary circuits, while providing a protective circuit breaker for each circuit in a common enclosure.

1. Pan assembly

2. Galvanized 1.2mm sheet

3 .Main switch: MCB, ISOLATOR, ELCB, MCCB up to 250A

4 .Outgoing: upto 72 poles way MCB

5. Plastic Lock/ Metal Lock

6. Surface/flush type

7. Adjusted mounting plate

8. Powder coating Ral7035 texture

9. IP42 for Metal Enclosure

10. IEC61439-1

Copper bar thickness1.5MM/2.0MM/2.5MM , match different type Main breaker

Additional information

Weight	60 kg
Dimensions	130 × 50 × 30 cm
Material	metal enclosure
Size	201210
Color	Gray

Technical Datasheet & Downloads

📄 Technical Documentation & Product Specifications

Download official engineering datasheets, certified test standards (IEC / UL / CE), wiring diagrams, and dimensional drawings for 3-Phase MCB/MCCB Main Breaker Distribution Board 4-16 Ways.

📥

Official Technical Datasheet (PDF) Complete electrical ratings, tripping characteristics, dimensions, and compliance specifications.

📐

2D/3D CAD & Dimensional Drawings STEP, DXF, and PDF CAD drawing files for panel builders and switchgear designers.

Technical FAQ & Selection Guide

💡 Frequently Asked Technical Questions & Selection Guide

Pure engineering specifications, tripping curve parameters, and electrical selection guidance for panel builders and system designers.

Curve Selection

How to choose between Tripping Curves B, C, and D for this miniature circuit breaker?

Curve B trips at 3–5 In (designed for resistive loads, electric heating, and domestic appliances with negligible inrush). Curve C trips at 5–10 In (the standard international choice for residential and commercial lighting, socket outlets, and small induction motors). Curve D trips at 10–14 In (specifically engineered for high-inrush inductive equipment such as industrial transformers, heavy motors, compressors, and welding circuits).

Breaking Capacity

How do I determine whether 6kA or 10kA breaking capacity is required for my installation?

Breaking capacity (Icn/Icu) must exceed the calculated prospective short-circuit fault current at the installation point. 6kA (IEC 60898-1) is standard for residential consumer units and sub-distribution branch circuits located downstream. 10kA (IEC 60947-2) is required for industrial facilities, main switchboards, commercial distribution panels, or circuits situated close to supply transformers where fault levels are high.

Poles & Neutral Isolation

How to choose the correct number of poles (1P, 1P+N, 2P, 3P, 3P+N, 4P) for single-phase and three-phase circuits?

For single-phase 230V circuits: 1P provides active phase protection; 1P+N or 2P isolates both live and neutral lines simultaneously (essential for TT earthing systems and sensitive sub-panels). For three-phase 400V systems: 3P protects balanced 3-wire motor loads; 3P+N or 4P is required for 4-wire mixed single-phase loads to ensure complete neutral disconnection during isolation.

DC vs AC Application

Can this circuit breaker be used in DC circuits (Solar PV, Battery Storage, Telecom)?

Standard AC breakers cannot safely extinguish DC arcs due to the absence of natural zero-crossing current. For DC circuits (60V to 1000V DC), select specialized DC breakers (such as DZ158-125 DC or NM8NDC series) equipped with permanent magnetic arc-blowout chutes and strictly observe polarity wiring to prevent arc re-ignition.

Modular Accessories & Interlocks

What modular accessories and mechanical interlocks can be fitted to this breaker?

Standard modular clip-on accessories can be mounted directly on the side without tools: OF (Auxiliary Contact for remote status indication), SD (Alarm Contact for trip fault signaling), MX (Shunt Trip for remote emergency tripping), MN (Under-voltage Release for voltage loss protection), and NXBZ mechanical interlock kits for manual generator/mains transfer switches.
