DELIXI ELECTRIC · Surge backup protector
Product overview
The DELIXI CDYNSCB is a dedicated backup protective device for voltage-limiting surge protective devices. Select it together with the SPD’s test class and surge rating, the required short-circuit capacity and the pole arrangement. The backup protector and SPD have different functions and are specified as a coordinated installation.
Technical selection summary
| Brand and series | DELIXI ELECTRIC CDYNSCB |
|---|---|
| Product type | Dedicated backup protective device for voltage-limiting SPDs |
| Referenced standard | NB/T 42150, dedicated protective devices for low-voltage surge protective devices |
| Rated operating voltage Uo | AC 230 / 400 V |
| Poles | 1P, 2P, 3P and 4P |
| T1 coordination reference | CDYNSCB-15: Iimp 15 kA with a 10/350 μs waveform |
| T2 coordination references | CDYNSCB-20 / -40 / -65 / -80 / -120: Imax 20 / 40 / 65 / 80 / 120 kA respectively, with an 8/20 μs waveform |
| Rated short-circuit capacity Icn | 65 or 100 kA; select the required grade in the complete order code |
| Minimum delayed operating current Id | 3 A; this is an operating-characteristic reference, not a surge rating |
| Terminals and supply direction | 2.5–25 mm² conductors; 2.5 N·m torque; top supply / bottom load |
| Degree of protection and indication | IP20; handle indication ON (closed) / OFF (open) |
| Operating ambient temperature | −25°C to +60°C |
The manufacturer limits this reference to voltage-limiting SPDs. Iimp, Imax, Icn and Id describe different characteristics and must not be interchanged. Use the T1 15 kA reference only with the matching 10/350 μs requirement; use the T2 references with the matching 8/20 μs requirement. Confirm the complete CDYNSCB code and SPD compatibility before ordering.
Typical applications
- Dedicated backup protection of matching voltage-limiting SPD branches
- Coordinated T1 or T2 surge-protection installations in AC distribution boards
