DELIXI · Electronic time delay relay
Product overview
The DELIXI JS14P time relay uses integrated circuits and crystal oscillators with digital thumbwheel dials for precise timing control. It offers on-delay and off-delay modes for automation panels, industrial machinery, and motor control circuits.
Technical selection summary
| Manufacturer / series | DELIXI JS14P series electronic time relay |
|---|---|
| Operating modes | On-delay (standard JS14P) or off-delay (JS14P-D) |
| Time setting mechanism | Digital thumbwheel dial switch; high delay accuracy and repeatability |
| Time range options | 26Y (0.1 s-99 h), 36Y (0.1 s-999 h), 9P9S (0.1 s-9.9 s), 999H (1 h-999 h); suffix-specific ranges |
| Rated control supply voltage | Discrete AC supplies: 12, 24, 36, 110, 127, 220 or 380 V; discrete DC supplies: 12, 24, 36, 110, 127 or 220 V. Wide-range versions: AC/DC 24–48 V (KD2) or AC/DC 100–240 V (KD1). Verify the complete supply suffix; these are separate versions. |
| Supply voltage tolerance | 85% to 110% of rated control supply voltage |
| Contact arrangement | Standard JS14P and JS14P-M: two changeover contacts; JS14P-D and JS14P-D/M: one changeover contact, as shown in the manufacturer wiring diagrams. |
| Contact rating | AC-15: 0.95 A at AC 380 V; 1.5 A at AC 240 V; 3 A at AC 120 V. DC-13: 0.27 A at DC 250 V; 0.55 A at DC 125 V. Resistive contact capacity: 3 A at AC 250 V; conventional thermal current Ith: 5 A. |
| Mounting options | Plug-in device mounting with matching socket, or M suffix for panel mounting |
| Operating temperature | -5 °C to +40 °C ambient temperature range |
| Standards compliance | GB/T 14048.5 (manufacturer user manual, August 2021, second edition) |
Technical ratings above follow the DELIXI JS14P user manual, August 2021, second edition, sections 3.3–3.6 and wiring diagrams. Time-range ordering codes follow the DELIXI April 2020 selection guide. Standard power-on and D power-off versions have different timing ranges and contact wiring; confirm the complete suffix and nameplate before ordering. The illustrated plain JS14P is not a JS14P-D. Do not combine supply, timing and mounting codes without checking the corresponding manufacturer specification.
Typical applications
- Time-delay sequencing in industrial machinery and motor starter panels
- Automated process timing, conveyor control, and HVAC cycle management
Specify your enquiry
For a focused quotation, include:
- Complete JS14P model designation including delay mode, time range code, and mounting suffix
- Control supply voltage, socket requirements, and order quantity
DELIXI JS14P user manual — August 2021, second edition (English PDF)
DELIXI April 2020 selection guide — JS14P ordering codes (PDF)
