DELIXI JD-6 Integrated Motor Protector Relay 63A-500A

DELIXI JD-6 integrated motor protector relay for circuit and motor open-phase, overload and locked-rotor protection.

Add to Enquiry
SKU: 1769744475363483648 Categories: Delixi Contactor & Overload Relays, Delixi Relays
  • Description
  • Catalog
Description

DELIXI ELECTRIC · Current-sensing motor protection relay

Product overview

The DELIXI JD-6 current-sensing motor protector operates with an external contactor to disconnect the motor supply after overload, stall or phase-loss faults. Select the exact current-range and control-supply version before ordering.

Technical selection summary

Manufacturer modelJD-6; common version without the A suffix
Manufacturer current ranges63–150 / 63–400 / 100–250 / 250–500 A; separate range constructions, not one universal setting
Main circuit / control supplyMain-circuit reference AC 380 V and below; control supply AC 220 V or AC 380 V, 50/60 Hz
Protection / trip classCurrent-sensing overload, stall and phase-loss protection; class 10A
Phase-loss response≤3 s for loss of any phase under the stated test conditions
Auxiliary contacts1NO + 1NC
Auxiliary contact dutyAC-15: 0.47 A at AC 220 V; resistive-load capacity AC 220 V 5 A / AC 380 V 3 A is a different rating
Housing / mountingIP50; TH35 mounting rail or screw mounting per drawing
Environment / standard−5 to +40 °C; altitude ≤2000 m; GB/T 14048.4

Use the exact wiring diagram and motor nameplate current. The common JD-5/JD-6 versions require their working supply and sensed three-phase current to be switched synchronously and are not suitable for star-delta changeover. A-suffix versions have different setting and operating behaviour. The relay controls an external switching device; it is not a motor short-circuit breaker.

Typical applications

  • Motor protection through a coordinated contactor circuit
  • Replacement of the same current-sensing protector construction

Official instructions:

Catalog
NameSizeRelease timeOperate
Delixi JD-6 Integrated Motor Protector Relay 63A-500A.pdf533.83 KB2026-11-14Download
