Delixi Electric CDM6Z DC Moulded Case Circuit Breaker MCCB
| Product Name | CDM6Z DC Moulded Case Circuit Breaker |
| Brand | DELIXI ELECTRIC |
| Model | CDM6Z |
| Product Type | DC MCCB |
| Rated Operating Voltage | DC250V / DC500V / DC750V / DC1000V |
| Rated Current Range | 63A-630A |
| Shell Frame Current | 125AF / 250AF / 400AF / 630AF |
| Poles | 2P / 3P / 4P |
| Protection Class | IP20 |
| Operating Temperature | -5°C to +40°C |
| Storage Temperature | -40°C to +70°C |
| Altitude | ≤2000m |
| Pollution Level | 3 |
| Application | Photovoltaic, charging pile, power supply, rail transport, communication |
| Standard | GB/T 14048.1, GB/T 14048.2, IEC 60947-1, IEC 60947-2 |
DELIXI CDM6Z DC moulded case circuit breaker for photovoltaic, charging pile and DC power distribution applications. 63A-630A, up to DC1000V, 2P/3P/4P.
