CHINT RT29 Fuse with Cylindrical Cap

Name: CHINT RT29 Fuse with Cylindrical Cap
Brand: CHINT
SKU: 1769744607349841920

Brand:Chint
Brand Name:Chint
Place of Origin:China
Use:LOW VOLTAGE
Model Number:RT29
Safety Standards:IEC
Breaking Capacity:High

Rated Voltage

Size

Rated Current (A)

Description

Chint RT29-16 RO14 8×32 2A 4A 6A 10A 16A RT29-125 RO17 22×58 10A 16A 20A 25A 32A 40A 50A 63A 80A 100A 125A Chnt Fuse

Chint RT 29 type fuse with cylindrical cap applies to distribution configuration of AC 50Hz, rated voltage 500V and rated current of 125A for protection from overload and short-circuit. (This type of fuse is not recommended of using in the electric capacity cabinet, if so, RT36-00 shall be used as replacement). Fuse equipped with impinger can be used as open-phase protection for the electric motor. Fuse-link for general service with full range of breaking capacity shall be “gG” type which can be used for line protection.

Additional information

Size	10×38, 14×51, 22×58
Rated Current (A)	2A, 4A, 6A, 8A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A, 80A, 100A
Rated Voltage	AC 400V, AC 500V, AC 690V
