CHINT NRZ28-20 Photovoltaic DC Fuse
Click to enlarge
Home Chint Electrical Materials Chint Fuse & Disconnectors CHINT NRZ28-20 Photovoltaic DC Fuse
Chint NH40SZ Automatic Changeover Switch ATS
Chint NH40SZ Automatic Changeover Switch ATS
Back to products
NewTrend XZDB Metal Consumer Unit, 4-22 Way
NewTrend XZDB Metal Consumer Unit, 4-22 Way

CHINT NRZ28-20 Photovoltaic DC Fuse

Brand Name:Chint
Place of Origin:China
Use:LOW VOLTAGE
Model Number:NRZ28-20
Safety Standards:IEC
Breaking Capacity:High
Brand:Chint
Model
Rated Current (A)
Add to Enquiry
SKU: 1600514751046 Category: Chint Fuse & Disconnectors
  • Description
  • Catalog
Description

CHINT · Photovoltaic fuse

Product overview

The CHINT NRZ28-20 is a gPV fuse link for photovoltaic DC protection. Match the actual fuse current, holder and circuit fault duty.

Technical selection summary

Manufacturer modelNRZ28-20; fuse link and matching base must be specified separately
Rated current entries2A, 4A, 6A, 8A, 10A, 12A, 15A, 16A, 20A
Rated voltageDC 1000 V in the NRZ28-20 manufacturer table
Utilization categorygPV, full-range DC breaking for photovoltaic protection
Breaking-capacity reference20 kA; the manufacturer table separately identifies a 35 kA 15 A version, which needs its own exact marking
Installation / standardApply enclosure, temperature and altitude derating; IEC 60269-6 / GB/T 13539.6 reference

Select the exact marked version rather than combining family voltage and current extremes. A 1500 V or 25–32 A variant is not established by this NRZ28-20 reference. Confirm PV string conditions and the matching holder.

Typical applications

  • Distribution and control assemblies matched to the specified device
  • Replacement procurement using the complete CHINT model

Product reference images and drawings

Use the applicable manufacturer model row, connection and outline drawing. Retained family references may show other versions.

NRZ28-20 technical reference 1NRZ28-20 technical reference 2NRZ28-20 technical reference 3NRZ28-20 technical reference 4
Catalog
NameSizeRelease timeOperate
Chint NRZ28-20 Photovoltaic DC Fuse.pdf480.60 KB2026-11-14Download
