Wire crimping pin terminal Solderless terminal BLUE PTV2-9 PTV2-10 PTV2-12 PTV2-13 YELLOW PTV5.5-13 Pre Insulated Pin Terminals
Size of cable:1.5-2.5mm2 (America standard AWG 16-14), Max Current =27A
| ITEM NO | DIMENSION | Color | |||
| Fφ | L | H | Dφ | ||
| mm | mm | mm | mm | ||
| PTV2-9 | 1.9 | 19 | 10 | 4.3 | blue |
| PTV2-10 | 1.9 | 20 | |||
| PTV2-12 | 1.9 | 22 | |||
| PTV2-13 | 1.9 | 23 | |||
Size of cable:1.5-2.5mm2 (America standard AWG 16-14), Max Current =48A
| ITEM NO | DIMENSION | Color | |||
| Fφ | L | H | Dφ | ||
| mm | mm | mm | mm | ||
| PTV5.5-13 | 2.8 | 25.5 | 12.5 | 6.7 | yellow |
