Butt Crimp Terminal BV1.25 BV2 BV5.5 BV8 BV14 BV22 BV38 splice Electrical wiring Vinyl Insulated Butt Connector
| ITEM NO | Cable Size | DIMENSION | Imax | INSULATION COLOR |
|||
| A.W.G | mm2 | l | dφ | L | |||
| mm | mm | mm | |||||
| BV1.25 | 22-16 | 0.5-1.5 | 15 | 4.4 | 26 | 16A | Red |
| BV2 | 16-14 | 1.5-2.5 | 15 | 5.1 | 26 | 27A | Blue |
| BV5.5 | 12-10 | 4-6 | 15 | 6.8 | 26 | 48A | Yellow |
| BV8 | #8 | 6-10 | 21 | 8.5 | 32 | 62A | Red |
| BV14 | #6 | 10-16 | 26 | 9.5 | 42 | 88A | Blue |
| BV22 | #4 | 16-25 | 29 | 10.5 | 50 | 115A | Yellow |
| BV38 | #2 | 35-50 | 32 | 14.5 | 55 | 160A | Red |
