LC1-D Series AC Magnetic Contactor LC1-D09 to LC1-D95

Name: LC1-D Series AC Magnetic Contactor LC1-D09 to LC1-D95
Brand: Newtrend or OEM brand
SKU: 1770407392152920064

Electricity Type:AC
Brand Name:Newtrend or OEM brand
Place of Origin:China
Model Number:LC1-D
Phase:3
type:Magnetic contactor

Poles

Rated Current (AC-3)

Coil Voltage

Request a Quote

Send quantities and requirements together. Availability and final specifications are confirmed with your quotation.

SKU: 1770407392152920064 Category: Others

Description

LC1-D09 LC1-D12 LC1-D18 LC1-D25 LC1-D32 LC1-D40 LC1-D50 LC1-D65 LC1-80 LC1-D95 equivalent to Chint CJX2 NC1 AC Contactor

1. Application

LC1-D (CJX2) series AC Magnetic Contactor is suitable for using in the circuits up to the rated voltage 660V AC50Hz or 60Hz, rated current up to 620A, for making, breaking, frequently starting & controllingthe AC motor. Combined with the auxiliary contact block, timer delay & machine-interlockingdevice etc, it becomes the delay contactor, mechanical interlocking contactor, star-delta starter.With the thermal relay, it is combined into the electromagnetic starter. The product conforms toIEC60947-4-1 stardand.

2. Specification

Type		LC1-D09	LC1-D12	LC1-D18	LC1-D25	LC1-D32	LC1-D40	LC1-D50	LC1-D65	LC1-D80	LC1-D95
Rated workingcurrent (A)	AC3	9	12	18	25	32	40	50	65	80	95
Rated workingcurrent (A)	AC4	3.5	5	7.7	8.5	12	18.5	24	28	37	44
Standardpower ratingsof 3-phasemotors50/60Hz incategory AC-3	220/230V	2.2	3	4	5.5	7.5	11	15	18.5	22	25
	380/400V	4	5.5	7.5	11	15	18.5	22	30	37	45
	415V	4	5.5	9	11	15	22	25	37	45	45
	500V	5.5	7.5	10	15	18.5	22	30	37	55	55
	660/690V	5.5	7.5	10	15	18.5	30	33	37	45	55
Rated heat current (A)		20	20	32	40	50	60	80	80	125	125
Electrical life	AC3 (x10⁴)	100	100	100	100	80	80	60	60	60	60
Electrical life	AC4 (x10⁴)	20	20	20	20	20	15	15	15	10	10
Mechanical life (x10⁴)		1000	1000	1000	1000	800	800	800	800	600	600
Number of the contacts	3P+NO					3P+NC+NO
Number of the contacts	3P+NC					3P+NC+NO

Type		LC1-D115	LC1-D150	LC1-D170	LC1-D205	LC1-D245	LC1-D300	LC1-D410	LC1-D475	LC1-D620
Rated workingcurrent (A)	AC3	115	150	170	205	245	300	410	475	620
	AC4	52	60	75	85	105	117	138	147	180
Standard powerratings of 3-phase motors50/60Hz incategory AC-3	220/230V	30	40	55	63	75	100	110	147	200
	380/400V	55	75	90	110	132	160	220	265	335
	415V	59	80	100	110	132	180	220	280	375
	500V	75	90	110	129	160	200	250	355	400
	660/690V	80	100	110	129	160	220	280	355	450
Rated heat current (A)		200	250	250	275	315	400	500	700	1000
Electrical life	AC3 (x10⁴)	200	60	60	50	50	50	30	30	20
Electrical life	AC4 (x10⁴)	15	15	15	15	15	15	8	8	5
Mechanical life (x10⁴)	300	300	300	300	300	300	300	100	100	100

3. Standard Control Circuit Voltage

Volts	24	42	48	110	220	230	240	380	400	415	440	500	600
50Hz	B5	D5	E5	F5	M5	P5	U5	Q5	V5	N5	R5	S5	Y5
60Hz	B6	D6	E6	F6	M6	–	U6	Q6	–	–	R6	–	–
50/60Hz	B7	D7	E7	F7	M7	P7	U7	Q7	V7	N7	R7	–	–

Volts

110

220

230

240

380

400

415

440

500

600

50Hz

60Hz

–

50/60Hz

–

Additional information

Rated Current (AC-3)	9A, 12A, 18A, 25A, 32A, 40A, 50A, 65A, 80A, 95A
Coil Voltage	AC 24V, AC 36V, AC 110V, AC 220V, AC 380V
Poles	3P
