NewTrend / OEM · High-voltage DC relay contactor
Product overview
The EV30ADXL reference describes a compact DC contactor with a 30 A DC-1 load-current entry. Select normally open or normally closed construction and the exact coil supply.
Technical selection summary
| Model | EV30ADXL |
|---|---|
| Load-current reference | 30 A DC-1; confirm working voltage and conditions |
| Contact version | Normally open or normally closed; full code required |
| Control selection | Confirm the exact DC coil voltage and wiring |
| Duty distinction | Continuous load, maximum switching and short-duration fault entries are separate quantities |
Keep continuous-load current separate from the reference maximum-switching and short-duration fault-current entries. Confirm their voltage, duration and test conditions. The source lists alternative coil and contact versions; certification and IP claims require exact-unit documents.
Product reference images and drawings
Use the matching model and version in the reference data. Confirm the applicable rating, test conditions and dimensions against the exact supplied unit.
Product Type | EV30ADXL |
| Contact form | 1 NO(SPST-NO) or 1NC(SPST-NC) |
| Coil Rated voltage(DC V) | 6V,12V,24V,36V,48V,60V,72V,84V,120V,150V etc. |
| Contact voltage(DC V) | 5-1000V |
| Contact circuit rated load current (DC-1) | 30A |
| Typical voltage drop across contacts per 30A | <80mV |
| the cooling pull-in voltage at (20±5)℃ (V) | <70% |
| the cooling drop-out voltage at (20±5)℃(V) | <35%,<5% |
| Working voltage range of 40 degrees celsius coil | 0.8-1.2Us |
| Drop-out time(n/o contacts to open) | 20ms |
| Pull-in time (n/o contacts to close) | 10ms |
| connect the maximum contact bounce time | 10ms |
| Disconnect the maximum contact bounce time | 7ms |
| Insulation Resistance | 100MΩ |
| Electric strength to resist | 50Hz/60Hz 2200VAC 1minute |
| Typical fault currents which can be ruptured | 400A/5ms at 48V DC |
| Coil power (W) | 2-7 |
| Temperature rise of coil (K) | ≤35 |
| Temperature rise on outgoing terminal (K) | ≤65 |
| Electric life | 20000 times |
| Mechanical life | 300 thousand times |
| Work specification | Continuous |
| Contact material | Alloy |
| Inrush time(Max) | 130ms |
| Maximum switching current | 300A 320VDC(More than 1 times) |
| Maximum switching power | 100kW |
| Load terminal type | M5 Rose |
| Coil terminal type | 0.3 square silicone wire, 390mm long |
| Testing organization certification | CE,FCC,RoHS |
| Contact lead M5 tightening torque(N.m) | <2.5 appropriate |
| Coil lead mode | Wire dipping tin |
| Ambient temperature | -40~+85℃ |
| Relative humidity | +20℃ 98% |
| Vibration freq. atthe fixed position | 3G, 1~50Hz amplitude 0.5mm |
| concussion | (60~100) time/minute,Acceleration≤4g |
| Altitude | 2000m |
| Installation direction | Random |
| International Protection | IP68 |
