NewTrend CH Type Load Center, 2–24 Spaces


You save

This NewTrend CH-type load center is a branch-distribution panel listing for CH-style breaker configurations. Confirm the exact breaker fit and approved assembly for the destination market; a compatible format alone does not establish certification.

Material
Size
Add to Enquiry
SKU: 62460653600 Category: CH Load Center
  • Description
  • Catalog
Description

NewTrend · CH

Product overview

NewTrend CH load centers provide branch-circuit distribution for residential, commercial and light-industrial indoor installations.

Technical selection summary

ModelCH
EnclosurePowder-coated metal enclosure
Supply voltage120/240V AC
Breaker constructionPlug-in
Supply systemSingle phase, three-wire

Model reference

ModelCircuitsVoltageMain ratingHWD
CH270F2120/240V AC70A23615085
CH4125F4120/240V AC125A32020685
CH4125S4120/240V AC125A29618285
CH6125F6120/240V AC125A32020685
CH6125S6120/240V AC125A29618285
CH8125F8120/240V AC125A32226490
CH8125S8120/240V AC125A29824090
CH12125F12120/240V AC125A390340114
CH12125S12120/240V AC125A364314114
CH16125F16120/240V AC125A390340114
CH16125S16120/240V AC125A364314114
CH20125F20120/240V AC125A465340114
CH20125S20120/240V AC125A441314114
CH24125F24120/240V AC125A465340114
CH24125S24120/240V AC125A441314114

Typical applications

  • Residential branch-circuit distribution
  • Commercial and light-industrial electrical panel assemblies

Product reference images and drawings

Newtrend H8c18cf0d86e64e53aadc490b91fbf5f8W - Low Voltage Electrical Product, 10+ Years Manufacturing Experience
Newtrend H8c18cf0d86e64e53aadc490b91fbf5f8W – Low Voltage Electrical Product, 10+ Years Manufacturing Experience
Newtrend H5dc763af3b634a118735bb1b813f5dd8F - Low Voltage Electrical Product, 10+ Years Manufacturing Experience
Newtrend H5dc763af3b634a118735bb1b813f5dd8F – Low Voltage Electrical Product, 10+ Years Manufacturing Experience
Newtrend H2878f27d80c94a6ebf0e91a0180a1d98A - Low Voltage Electrical Product, 10+ Years Manufacturing Experience
Newtrend H2878f27d80c94a6ebf0e91a0180a1d98A – Low Voltage Electrical Product, 10+ Years Manufacturing Experience
Newtrend Haaa0c12197734ebd916eee61da812ef8s - Low Voltage Electrical Product, 10+ Years Manufacturing Experience
Newtrend Haaa0c12197734ebd916eee61da812ef8s – Low Voltage Electrical Product, 10+ Years Manufacturing Experience
Newtrend Hf085bae8c570405a828d8ce20f038181p - Low Voltage Electrical Product, 10+ Years Manufacturing Experience
Newtrend Hf085bae8c570405a828d8ce20f038181p – Low Voltage Electrical Product, 10+ Years Manufacturing Experience
Newtrend H69b6cedd632844ffa9edad12d6cb7bdbO - Low Voltage Electrical Product, 10+ Years Manufacturing Experience
Newtrend H69b6cedd632844ffa9edad12d6cb7bdbO – Low Voltage Electrical Product, 10+ Years Manufacturing Experience
CH series product photographs and technical reference
CH series product photographs and technical reference
