NewTrend aM Cylindrical Motor Fuse Links, 8×31-22x58mm

NewTrend cylindrical aM fuse links for motor circuits. Choose a base fuse model; size, current and AC voltage are linked to that exact row.

Model
Rated Current
Rated Voltage
Fuse Version
Size
Indicator
Add to Enquiry
SKU: 1770410563625558016 Category: Fusegear
  • Description
  • Catalog
Description

NewTrend · aM

Product overview

NewTrend cylindrical aM fuse links for motor circuits. Choose a base fuse model; size, current and AC voltage are linked to that exact row.

Technical selection summary

ParameterSpecification
Utilisation categoryaM: motor-circuit short-circuit protection; separate overload protection is required
Breaking capacity80kA per exact aM selection table
Dimensions8×31,10×38,14×51,22x58mm
VoltageModel-specific AC400/500/550/690V; never select voltage independently from current and size
IndicationStandard,indicator L or striker S; use the exact full part number below
HolderMatched holder is identified separately; the reference holder photo may contain a gG fuse and is not the selected aM rating

These are aM short-circuit fuse links, not full-range overload protection. The generic100kA/1000V statements from other fuse classes do not apply to this table.

SizeAClassAC voltageBreakingStandardIndicatorStrikerHolder
8×31 mm1aM400Vac80KAC08M1C08M1LC08M1SRT18-20X
8×31 mm2aM400Vac80KAC08M2C08M2LC08M2SRT18-20X
8×31 mm4aM400Vac80KAC08M4C08M4LC08M4SRT18-20X
8×31 mm6aM400Vac80KAC08M6C08M6LC08M6SRT18-20X
8×31 mm8aM400Vac80KAC08M8C08M8LC08M8SRT18-20X
10×38 mm0.16aM550Vac80KAC10M0-16C10M0-16LC10M0-16SRT18-32X
10×38 mm0.25aM550Vac80KAC10M0-25C10M0-25LC10M0-25SRT18-32X
10×38 mm0.5aM550Vac80KAC10M0-5C10M0-5LC10M0-5SRT18-32X
10×38 mm1aM550Vac80KAC10M1C10M1LC10M1SRT18-32X
10×38 mm2aM550Vac80KAC10M2C10M2LC10M2SRT18-32X
10×38 mm4aM550Vac80KAC10M4C10M4LC10M4SRT18-32X
10×38 mm6aM550Vac80KAC10M6C10M6LC10M6SRT18-32X
10×38 mm8aM550Vac80KAC10M8C10M8LC10M8SRT18-32X
10×38 mm10aM550Vac80KAC10M10C10M10LC10M10SRT18-32X
10×38 mm12aM550Vac80KAC10M12C10M12LC10M12SRT18-32X
10×38 mm16aM550Vac80KAC10M16C10M16LC10M16SRT18-32X
10×38 mm20aM400Vac80KAC10M20C10M20LC10M20SRT18-32X
10×38 mm25aM400Vac80KAC10M25C10M25LC10M25SRT18-32X
10×38 mm32aM400Vac80KAC10M32C10M32LC10M32SRT18-32X
14×51 mm0.25aM690Vac80KAC14M0-25C14M0-25LC14M0-25SRT18-63X RT18L-63
14×51 mm1aM690Vac80KAC14M1C14M1LC14M1SRT18-63X RT18L-63
14×51 mm2aM690Vac80KAC14M2C14M2LC14M2SRT18-63X RT18L-63
14×51 mm4aM690Vac80KAC14M4C14M4LC14M4SRT18-63X RT18L-63
14×51 mm6aM690Vac80KAC14M6C14M6LC14M6SRT18-63X RT18L-63
14×51 mm8aM690Vac80KAC14M8C14M8LC14M8SRT18-63X RT18L-63
14×51 mm10aM690Vac80KAC14M10C14M10LC14M10SRT18-63X RT18L-63
14×51 mm12aM690Vac80KAC14M12C14M12LC14M12SRT18-63X RT18L-63
14×51 mm16aM690Vac80KAC14M16C14M16LC14M16SRT18-63X RT18L-63
14×51 mm20aM690Vac80KAC14M20C14M20LC14M20SRT18-63X RT18L-63
14×51 mm25aM690Vac80KAC14M25C14M25LC14M25SRT18-63X RT18L-63
14×51 mm32aM690Vac80KAC14M32C14M32LC14M32SRT18-63X RT18L-63
14×51 mm40aM400Vac80KAC14M40C14M40LC14M40SRT18-63X RT18L-63
14×51 mm50aM400Vac80KAC14M50C14M50LC14M50SRT18-63X RT18L-63
14×51 mm63aM400Vac80KAC14M63C14M63LC14M63SRT18-63X RT18L-63
22×58 mm2aM690Vac80KAC22M2C22M2LC22M2SRT18L-125
22×58 mm4aM690Vac80KAC22M4C22M4LC22M4SRT18L-125
22×58 mm6aM690Vac80KAC22M6C22M6LC22M6SRT18L-125
22×58 mm8aM690Vac80KAC22M8C22M8LC22M8SRT18L-125
22×58 mm10aM690Vac80KAC22M10C22M10LC22M10SRT18L-125
22×58 mm12aM690Vac80KAC22M12C22M12LC22M12SRT18L-125
22×58 mm16aM690Vac80KAC22M16C22M16LC22M16SRT18L-125
22×58 mm20aM690Vac80KAC22M20C22M20LC22M20SRT18L-125
22×58 mm25aM690Vac80KAC22M25C22M25LC22M25SRT18L-125
22×58 mm32aM690Vac80KAC22M32C22M32LC22M32SRT18L-125
22×58 mm40aM690Vac80KAC22M40C22M40LC22M40SRT18L-125
22×58 mm50aM690Vac80KAC22M50C22M50LC22M50SRT18L-125
22×58 mm63aM690Vac80KAC22M63C22M63LC22M63SRT18L-125
22×58 mm80aM500Vac80KAC22M80C22M80LC22M80SRT18L-125
22×58 mm100aM500Vac80KAC22M100C22M100LC22M100SRT18L-125
22×58 mm125aM400Vac80KAC22M125C22M125LC22M125SRT18L-125

Typical applications

  • Electrical panel assembly and installation

Open technical reference image

Product reference images and drawings

aM technical reference 1
