Product overview
NewTrend CH-form load centers for single-phase 120/240V distribution. Choose the supported space/current version and surface or flush mounting.
Technical selection summary
| Parameter | Specification |
|---|---|
| Space / bus matrix | 2spaces 70A; 4/6/8/12/16/20spaces 125A; 24spaces 125A or 225A per source and owner confirmation |
| Service | AC120/240V, single phase |
| Mounting | SurfaceS orflushF; owner resolves the transposed source table |
| Construction | Galvanized steel, powder-coated grey; CH-form branch breaker construction |
| Circuit schedule | Spaces do not automatically equal double the circuit count; state the exact branch-device schedule |
| Dimensions | The retained original series table covers 2-16spaces only; 20/24space dimensions require the supplied current construction drawing |
| Supply identity | NewTrend/OEM; no inherited EatonUL/NEMA certification |
Owner confirms 20spaces 125A and 24spaces 125A/225A; unsupported 100A is removed. ApplyS=surface, F=flush, not the reversed old printed table. Final enclosure dimensions and branch-breaker fitment follow the quoted actual NewTrend assembly.
| Version | Spaces | Bus current |
|---|---|---|
| CH2 / 70A | 2 | 70A |
| CH4 / 125A | 4 | 125A |
| CH6 / 125A | 6 | 125A |
| CH8 / 125A | 8 | 125A |
| CH12 / 125A | 12 | 125A |
| CH16 / 125A | 16 | 125A |
| CH20 / 125A | 20 | 125A |
| CH24 / 125A | 24 | 125A |
| CH24 / 225A | 24 | 225A |
Typical applications
- Electrical distribution and motor control
Specify your enquiry
For a focused quotation, include:
- Selected model and configuration
- Quantity, installation requirements and destination
- Required supporting documents for the exact configuration
Open technical reference image
Product reference images and drawings
