Chint original NX8 Distribution Box 5 ways 8 ways 12 ways 15 ways 20 ways 24 ways Circuit Breaker Consumer Unit
1. General
1.1 Electric ratings: up to 100A, 230V, AC50/60Hz;
1.2 No. Of mounted units: 5, 6, 8, 12, 15, 20, 24;
1.3 On-load current (A): 100/1-phase;
1.4 Protection degree: IP30;
1.5 Standard: IEC61439-3(EN60670-24)
2. Features
2.1 The window of the consumer unit is designed with novel appearance and convenient operation. Open and close operation is flexible, and self-locking at the open status;
2.2 Inside the product, there is a neon indicator light to indicate status of power supply; having a elegant appearance and clear indication;
2.3 The interiorly mounted MCBs are all in compliance with relative IEC standards, 9mm modularized electric components are applicable, as well;
2.4 On request, various circuit combinations can be assembled; and the mounting capacity of the product units can be taken to 5~24 units;
2.5 Convenient and reliable operation, having exposed handle, and all live parts to be mounted inside the wall box ;
2.6 The consumer unit is designed with internal terminal blocks for connection of neutral line and protective grounding wire.
2.7 The enclosure of the unit is made of plastic material with metal structure.
