NewTrend · ZS /7.2
Product overview
NewTrend ZS three-pole vacuum contactors for7.2kV AC switching. Select main-contact current, separate coil supply and holding construction.
Technical selection summary
| Parameter | Specification |
|---|---|
| Main circuit | 3P,7.2kV,50Hz |
| Rated current | 160,250,400,630A |
| Power-frequency withstand | 32kV |
| Breaking current,25operations /20s | 160A:1280A;250A:2000A;400A:3200A;630A:5000A |
| Maximum breaking current,3operations /30s | 160A:3200A;250A:3200A;400A:4000A;630A:6000A |
| Auxiliary contacts | 4NO+3NC |
| Operating time | Opening<120ms;closing<150ms |
| Contact gap / overtravel | 4+/-0.5mm / at least1.2mm |
| Endurance | Mechanical1million / electrical300000 operations |
| Coils / holding | AC orDC110/220/380V; electrical hold or mechanical latch per original description; verify final latch suffix and control circuit before ordering |
The main-circuit rating is7.2kV AC, not the coil voltage. The selected values form an enquiry configuration; the final factory latch/control suffix must be confirmed.24V and3.6kV variants are outside the verified table.
Typical applications
- Electrical panel assembly and installation
