Chint NXU-IIG Surge Arrester 20kA 40kA 65kA 100kA 275V 320V 385V 440V 85Vdc 350Vdc 500Vdc 1P 2P 3P 4P CHNT SPD Surge Protector
NXU- Ⅱ G Low-voltage Surge Arrester
(NXU- Ⅱ G/F is with alarm terminal)
General
1 Certificates:international certificates are under proceeding;
2 Number of pole: 1,2,3,4,1P+N,3P+N;
3 Electric ratings: AC (275V 320V 385V 440V), DC (85V 350V 500V)
4 Application:Protect electric system and on-loading electrical apparatus from thunder and instantaneous over-voltage;
5 Standard:IEC/EN 61643-11
